OBO-40008F

Buzzer Mylar Speaker >Ø40mm and <Ø50mm
DYNAMIC SPEAKER Ø40mm 8 ohm 10W

Documentation

  • Type
    Buzzer Mylar Speaker >Ø40mm and <Ø50mm
  • Brand name
    Obo Pro.2
  • Power [W]
    8W
  • Impedenza
  • dB
    80
  • Dimension [mm;mt]
    Ø40mm
  • Data sheet

  • Contact us

Obo Pro.2

Buzzer -> Mylar Speaker -> >Ø40mm and <Ø50mm

Mylar speaker is a kind of micro speaker unit that uses a diaphragm made of Mylar material. Mylar speakers have an ultra-thin design and a light and clear voice. Widely used in building security industry, automotive electronics, medical devices, mobile internet devices, etc.

Image Code Power [W] Impedenza dB Dimension [mm;mt]
sJpbb07c0QXnGKP OBO-40008F-01

0,2W
|
|
80
|
Ø40mm

0,2W 80 Ø40mm
OBO-40008F-03

0,5W
|
|
84
|
Ø40mm

0,5W 84 Ø40mm
OBO-40008F-04

1W
|
|
87
|
Ø40mm

1W 87 Ø40mm
OBO-40008F-27

2W
|
|
86
|
Ø40mm

2W 86 Ø40mm
OBO-40032F-01

0,2W
|
32Ω
|
80
|
Ø40mm

0,2W 32Ω 80 Ø40mm
RyFXnpNbJZBCgUV OBO-40016F-05

0,5W
|
16Ω
|
86
|
Ø40mm

0,5W 16Ω 86 Ø40mm
OBO-45008F

5W
|
|
81
|
Ø45mm

5W 81 Ø45mm
OBO-62008G-01

10W
|
|
72
|
Ø45mm

10W 72 Ø45mm
TsmeHKtDOXlmGo7 OBO-40204F-01

5W
|
|
84
|
Ø42mm

5W 84 Ø42mm
n7O4hiKUtfFnw OBO-40008F

8W
|
|
80
|
Ø40mm

8W 80 Ø40mm
