AK55HB120/160

AK55HB120/160

Power Module Thyristor
THYRISTOR AK 1200V 55A

Documentation

  • Type
    Power Module Thyristor
  • Brand name
    Sanrex
  • Vrrm [V]
    1200-1600V
  • Ifa[A]
    55A
  • Tc [°C]
    85°C
  • I2t
    5000A2s
  • Ifsm
    -
  • Vfm
    -
  • Data sheet
    download AK55HB120-160.pdf

  • Contact us

Sanrex

Power Module -> Thyristor

The thyristor or SCR (Silicon Controlled Rectifier) is an electronic component, very similar to the diode. The only difference is that direct conduction occurs only following the application of a suitable signal on the gate terminal. The typical use of Thyristors is in controllable voltage rectifiers, they are able to supply adjustable DC voltages from a fixed AC voltage.

Image Code Vrrm [V] Ifa[A] Tc [°C] I2t Ifsm Vfm
VghqkmcnQqLFzTJ AK55HB120/160

1200-1600V
|
55A
|
85°C
|
5000A2s
|
-
|
-

 1200-1600V 55A 85°C 5000A2s - - THYRISTOR AK 1200V 55A
EsotGdtZfjfzl5E SBA500AA160

1600V
|
500A
|
66°C
|
416A2S
|
-
|
-

 1600V 500A 66°C 416A2S - - THYRISTOR THYRISTOR 1600V 500A ISOLATED PKG
JZkxhytmF3LAwEB PWB130A40

400V
|
130A
|
112°C
|
5100A2S
|
-
|
-

 400V 130A 112°C 5100A2S - - Power Module Thyristor Pwb 400V 130A
PWB200AA40

400V
|
200A
|
121°C
|
1499400A2s
|
5400/6000A
|
1,20V

 400V 200A 121°C 1499400A2s 5400/6000A 1,20V POWER MODULE THYRISTOR PWB 400V 200A
ICEmy7BoQkMv0Ng SSA500AA160

1600V
|
500A
|
66°C
|
416000A2s
|
-
|
-

 1600V 500A 66°C 416000A2s - - POWER MODULE HIGH CURRENT THYRISTOR 1600V 500A
