DRIVERS FOR LIGHTING
RGB LED Driver for Architectural Lighting and backlight & lighting solutions for consumer electronics.
Bi-Directional Transmission:
In traditional designs, the Error report feature is achieved by connecting one additional wire from the last IC to the controller and a signal buffer. With I/O bi-directional transmission, the same wire connecting the controller to the ICs is used to report information back to the control system. This not only improves communication between control systems and light fixtures but also saves wire costs.
Application: Consumer Electronics RGB LED Lighting, LED Cluster, LED Strip, Mesh Display
Macroblock Inc.
LED Drivers -> LED backlight driver
Image | Code | Supply Voltage[V] | Output Ch. | Const.Output Current Range/Ch. | Time-multiplexing | Package |
---|---|---|---|---|---|---|
![]() |
MBI1838
8-40V | 8 | 80mA | - | GTS : TSSOP24L-173-0,65
|
8-40V | 8 | 80mA | - | GTS : TSSOP24L-173-0,65 |
LED Drivers -> Led Lighting Driver
With constant current technology, the All-Ways-On series features instant on/off control of LED drivers. By adjusting the output current through a registor and setting the LED brightness through the Pulse Width Modulation (PWM), the All-Ways-On series provides simple and reliable control of LED operation. Build-in thermal protection function is also added to the All-Ways-On series LED drivers to prevent ICs from overheating.
Image | Code | Supply Voltage[V] | Output Ch. | Const.Output Current Range/Ch. | Time-multiplexing | Package |
---|---|---|---|---|---|---|
![]() |
MBI1816
5V | 16 | 60mA | - | TSSOP20
|
5V | 16 | 60mA | - | TSSOP20 |
LED Drivers -> RGB Led Driver
RGB LED drivers for LED strip, mesh display, architectural lighting, and backlight & lighting solutions for consumer electronics.
Image | Code | Supply Voltage[V] | Output Ch. | Const.Output Current Range/Ch. | Time-multiplexing | Package |
---|---|---|---|---|---|---|
![]() |
MBI6020
3-5.5V | 3 | 5-50mA | - | SSOP16, QFN16
|
3-5.5V | 3 | 5-50mA | - | SSOP16, QFN16 |
MBI6024
3-5.5V | 3x4 | 3-45mA | - | SSOP24, QFN24
|
3-5.5V | 3x4 | 3-45mA | - | SSOP24, QFN24 | |
MBI6030
5V,7-30V | 3 | 5-150mA | - | SSOP16, QFN24
|
5V,7-30V | 3 | 5-150mA | - | SSOP16, QFN24 | |
MBI6034
3 | 150mA | - | SSOP24, TSSOP24, QFN24
|
3 | 150mA | - | SSOP24, TSSOP24, QFN24 | ||
MBI6120
4.5-17V | 3 | 3-20mA | - | SOP8
|
4.5-17V | 3 | 3-20mA | - | SOP8 | |
![]() |
MBI6027
3 | 5-45mA | - | QFN24
|
3 | 5-45mA | - | QFN24 | |
![]() |
MBI6023
3-5.5V | 3x4 | 3-45mA | - | SSOP24, QFN24
|
3-5.5V | 3x4 | 3-45mA | - | SSOP24, QFN24 |
MBI6033
3-5,5 - 6-24V | 3x4 | 3-45mA | - | SSOP24, GTS, GFN
|
3-5,5 - 6-24V | 3x4 | 3-45mA | - | SSOP24, GTS, GFN | |
![]() |
MBI6034Q
3.3-5.0V | 3x4 | 150mA | - | QFN24L-4x4-0.5
|
3.3-5.0V | 3x4 | 150mA | - | QFN24L-4x4-0.5 |
LED Drivers -> Driver convertitore DC/DC
Macroblock offre una vasta gamma di prodotti di driver per l'illuminazione a LED, tra cui regolatori lineari, controller AC/DC e convertitori DC/DC. Macroblock fornisce anche driver LED RGB a corrente costante a 3 e 12 canali per l'illuminazione architettonica.
Image | Code | Supply Voltage[V] | Output Ch. | Const.Output Current Range/Ch. | Time-multiplexing | Package |
---|---|---|---|---|---|---|
![]() |
MBI6661
9-60V | 1 | 1A | - | TO252,SOP8
|
9-60V | 1 | 1A | - | TO252,SOP8 |
![]() |
MBI6655
6-36V | 1 | 1A | - | SOP8, SOT89
|
6-36V | 1 | 1A | - | SOP8, SOT89 |
![]() |
MBI6671
4.5-65V | 1 | External Mosfet | - | TSSOP24
|
4.5-65V | 1 | External Mosfet | - | TSSOP24 |
![]() |
MBI6673
20-55V | 4 | External Mosfet | - | TSSOP24, QFN4×4-24
|
20-55V | 4 | External Mosfet | - | TSSOP24, QFN4×4-24 |
MBI6673GTS
9-55V | 4 | 5A | - | QFN4×4-24
|
9-55V | 4 | 5A | - | QFN4×4-24 | |
![]() |
MBI6672
6-60V | 1 | External Mosfet | - | TSSOP14
|
6-60V | 1 | External Mosfet | - | TSSOP14 |
LED Drivers -> Amuse Led Driver
Image | Code | Supply Voltage[V] | Output Ch. | Const.Output Current Range/Ch. | Time-multiplexing | Package |
---|---|---|---|---|---|---|
![]() |
MBIA045
3.3-5.0V | 16 | 1-45mA | - | SSOP24, QFN24
|
3.3-5.0V | 16 | 1-45mA | - | SSOP24, QFN24 |
MBIA128
3.3-5.0V | 12 | 5-40mA | 12x4 | TSSOP28-173-0.65/QFN28L-4X4-0.45
|
3.3-5.0V | 12 | 5-40mA | 12x4 | TSSOP28-173-0.65/QFN28L-4X4-0.45 |
