E1NDA-YJ1X7-F1

PLCC PLCC2 3030

Led PLCC 3030 Natural White 4000°K 140° 33.3lm 150mA Cri>80

Documentation

• Type
  PLCC PLCC2 3030
• Brand name
  Toyoda Gosei
• Alternatives
  • NF2W757ART-V1
• Colour
  Natural White
• CCT[°K]
  4000K
• Power [W]
  0.54W
• IF[mA]
  150mA
• CRI
  >80
• Luminous Flux[lm/mcd]
  33.3lm @65mA
• Data sheet
  E1NDA-YJ1X7-F1.pdf
• Other related articles
  HYPERSUNLIGHT GaN Led 3030
•
  Contact us

Toyoda Gosei

PLCC -> PLCC2 -> 3030

PLCC LED has a ultra high luminous efficacy, combined with the flexibility in design due to its slim and miniature size. PLCC 3030 LED series have ultra-high reliability and luminous efficacy. It can be used for automotive light, horticulture light, general light, signal light, indoor or outdoor light, etc.

Image	Code	Colour	CCT[°K]	Power [W]	IF[mA]	CRI	Luminous Flux[lm/mcd]
	E1NDA-YD1X7-F1 White | 6500K | 0.54W | 150mA | >80 | 33.3lm @65mA	White	6500K	0.54W	150mA	>80	33.3lm @65mA
	E1NDA-YE1X7-F1 White | 3000K | 0.54W | 150mA | >80 | 32.1lm @65mA	White	3000K	0.54W	150mA	>80	32.1lm @65mA
	E1NDA-YH1D7-F1 Day White | 5000K | 0.54W | 150mA | >80 | 35.8lm @65mA	Day White	5000K	0.54W	150mA	>80	35.8lm @65mA
	E1NDA-YJ1X7-F1 Natural White | 4000K | 0.54W | 150mA | >80 | 33.3lm @65mA	Natural White	4000K	0.54W	150mA	>80	33.3lm @65mA
	E1NDA-YK1X7-F1 White | 2700K | 0.54W | 150mA | >80 | 30.9lm @65mA	White	2700K	0.54W	150mA	>80	30.9lm @65mA
	E1NDA-YT1X7-F1 Warm White | 3500K | 0.54W | 150mA | >80 | 32.7lm @65mA	Warm White	3500K	0.54W	150mA	>80	32.7lm @65mA
	ENN01-SKSD7-F1 Warm White | 2700K | 0,3W | 100mA | 95 | 26lm	Warm White	2700K	0,3W	100mA	95	26lm
